TECHNICAL DATA

• Working height – 32 ft 3 in
• Platform height – 26 ft 3 in
• Platform length (outside) –  7 ft 7 in
• Platform length (extended) – 10 ft 7 in
• Extension length – 3 ft
• Platform width (outside) – 2 ft 8 in
• Storage height – 4 ft 4 in
• Height - stowed – 7 ft 2 in
• Overall width – 2 ft 8 in
• Length – 8 ft 2 in
• Wheelbase – 6 ft 1 in
• Ground clearance – 5 in
• Ground clearance - Pothole guards deployed – 1 in
• Drive speed – 0.6 - 2.0 mph
• Driveable at full height – up to 26 ft 3 in
• Gradeability – 23 %
• Tilt alarm – 2 °
• Lift / lower speed – 36 s / 42 s
• Turning radius (outside) – 7 ft 10 in
• Non-marking tires – 15x5
• Batteries – 24 V - 225 Ah (C20)
• Hydraulic system capacity – 7 gal
• Weight – 4,829 lbs
• Platform size (extended) – 10 ft 7 in x 2 ft 8 in
• Lift capacity (inside) – 500 lb (2 pers.)
• Lift capacity (outside) – N/A
• Lift capacity on the extension – 265 lb
