Lift height
Standard forks - up 24 ft 4 in
Standard forks - down 22 ft 7 in
Adjustable forks (up)  24 ft 4 in
Adjustable forks (down)  22 ft 7 in

Boom  23 ft 7 in
Height - stowed 7 ft 2 ¾ in
Length - stowed  2 ft 9 ⅜ in
- operating  6 ft 9 in
Width - stowed  30 ½ in
- stabilizers deployed  5 ft 4 ⅛ in
Stabilizers
Forks
Length 30 in
Width (outside) 23 in
Maximum load capacity
14 in 650 lbs
24 in 430 lbs
42 in 175 lbs
Ground clearance 2.5 in
Load height - minimum 6 in
Weight 404 lbs
Winch cranks/distance
High speed 4 cranks/ft
Low speed 15 cranks/ft
