ARTICULATED LIFT, 45'

ARTICULATED LIFT, 45'


TREE TRMMING: $500 deposit required

TECHNICAL DATA
Working height 51 ft
Platform height 45 ft
Horizontal outreach (from centerline) 27 ft
Horizontal outreach (from edge of footpad) 21 ft
Up and over height 20 ft 9 in
Lift capacity 500 lbs
Length - stowed 20 ft 8 in
Width stowed 5 ft 6 in
Height stowed 6 ft 8 in
Platform size 4 ft 1 in x 2 ft 9 in
Turntable rotation 350° non-continuous
Jib - length 4 ft 3 in
Jib - Vertical Motion 150° (+70 / -80)
Tow speed rating 65 mph
Leveling capability 12.5 °
Tire size ST 225/75 R15
Power source 4 x 6 V 245 amp-hr
Tongue weight (no options) 290 lbs
Weight (no options) 4200 lbs
Widest Point 13 ft 9 in
Widest Point 13 ft 6 in


** Rates and availability are subject to change

** Tax and other fees not show included in rate

Please call for more information regarding our ' AERIAL EQUIPMENT '

Make HAULOTTE
Model 4527A
1/2 Day Price $145.00
Daily Price $250.00
Weekend Price $314.00
Weekly Price $750.00
Monthly Price $2,250.00
More Information http://www.haulotte-usa.com/product/4527
