Engine
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Displacement
55 in³
Number of Cylinders
3
Horsepower
24.8 hp
Performance
Rated Operating Capacity (SAE)
850 lb
Tipping Load
2458 lb
Operating Weight
3103 lb
Ground Pressure (Rubber)
4.9 psi
Travel Speed
4.1 mph
Travel Speed - Reverse
2.9 mph
Capacities
Fuel Tank
7 gal
Hydraulic System
Pump Capacity
12 gal/min
System Relief @ Quick Couplers
2,900 psi
Auxiliary Std Flow
n/a
Dimension
Length
106.2 in
Width
35.6 in
Height
54.6 in
Height to Bucket Hinge Pin
80.9 in
Length of track on ground
40.6 in
Reach @ Maximum Height
18.6 in
Features
Lift-Arm Support
Auxiliary Hydraulics
Spark Arrestor Muffler
Bob-Tach Attachment System

Reverse Travel Stop Panel
Wide Track
Neutral Start Interlocks
Lift Arm Lockout With Manual Bypass
Tilt Lockout
Built-In Tie Down & Crane/Lift Locations
Ride-on Platform
