OPERATION U.S. METRIC
Transit forward 176 fpm 53.6 m/min
Transit reverse 136 fpm 41.5 m/min
Digging chain speed @ 3,600 rpm
19K 366 fpm 11 m/min
33/35K 309 fpm 94.2 m/min
Spoil handling
Auger type Single, open end
Auger diameter 17 in 432 mm
Trench cleaner type Mechanical
Trench cleaner size 4-6 in 102-152 mm
Operating weight (up to) 1,915 lb

TRENCH SIZE, MAX U.S. METRIC
Depth 36 in 914 mm
Width 6 in 152 mm
